FN SERIES THREE-SIDED FLUSH FRAMES

Default Promo Image Alt

The FN Series 3 sided flush narrow 1" (25 mm) face frames are designed to meet the requirements for light to maximum duty applications in both commercial and institutional buildings where a slim face profile is required. They are installed in both interior and exterior locations, and in virtually all types of buildings and wall constructions.

These frames are to be installed as part of the wall framing sequence. They can be specified and supplied as KD (knock-down) for field assembly prior to installation or welded for installation as a complete unit.





FEATURES AND BENEFITS

Strength, durability and ease of installation

  • FN Series: narrow 1” (25mm) face provides slim appearance to door opening
  • Attractive, tight and closed die-mitered corner connection; miter includes four corner tabs designed with concealed connection, eliminating need for continuous profile welding
  • Patented universal hinge preparations allow for easy field conversion from standard-weight .134” (3.3mm) thick hinges to heavyweight .180” (4.7mm) hinges
  • F Series: adjustable base anchors allow for installation adjustment when floor is not level
  • Factory prepared for field-installed silencers

Exceeds industry standards

  • Steelcraft is SDI Certified through regular audits to ensure manufacturing, performance and quality standard set by the Steel Door Institute
  • Overall frame construction exceeds ANSI A250.8-2017 (SDI-100), the standard set by SDI specifying sizes, design, materials, construction, finishing and performance for standard commercial steel doors and frames
  • Hardware preparations and reinforcements meet ANSI A250.6-2003, and locations meet ANSI/DHI A115, unless otherwise stated
  • Frames meet fire rating requirements; they are listed for installations requiring compliance to both neutral pressure testing (ASTM E152 and UL-10B) and positive pressure standards (UL-10C)
  • Factory-applied baked-on rust inhibiting primer meets ANSI A250.10-2011

Typical applications

Similar to F Series but boasts a narrow 1" face to minimize the appearance of frame for a more slender, aesthetic face dimension in architectural openings.

Technical Data Guide

For more complete information on FN Series Frames, download the Steelcraft Technical Data Manual.

  • FN Series (Pages 25-28): Includes Anchors, Hardware Preps, Lights, Fire Ratings
