LS Series Stainless Steel Doors

Default Promo Image Alt

LS Series Doors are designed and built to withstand the harshest environments. This solution utilizes all-stainless-steel construction, including reinforcement components. LS Series Doors are available in either 304 or 316 alloy for maximum durability and corrosion protection. Stainless steel stiffeners are epoxy-glued to eliminate surface imperfections associated with welding.


In addition to standard flush and panel doors, custom doors are available in a wide range of polished and etched finishes. Custom sizing, lites, and finishes combined with industry performance ratings can create an architectural design perfect for showcase projects.



FEATURES AND BENEFITS

Structural core strength and ease of installation

  • Polystyrene or polyurethane door cores to suit various applications
    • Stainless steel stiffeners available to be epoxy glued in
  • Seamless and interlocking edge
  • Stainless steel thickness up to 12 gauge
  • Exceptional corrosion resistance – 100% stainless steel
    • Type 304 Alloy – standard corrosion resistance
    • Type 316 Alloy - heavy duty corrosion resistance

Exceeds industry standards

  • Fire-rated up to Class A (3-hour)
  • Sound-rated to STC 46 on Single and 43 on Pairs (seals not included)
  • Hurricane-approved (NOA Dade County Florida)
  • Compliance with ASTM A666, ASTM E152, UL-10B, and USL-10C
  • Door construction meets the requirements of ANSI A250.8-2003 (SDI 100)
  • Hardware preparations and reinforcements are in accordance with ANSI A250.6-2003.
  • Locations are in accordance with ANSI/DHI A115; alternate locations are available
